Handheld Mobile Terminals
RS51
Enterprise handheld terminal for mixed-environment deployments with strong wireless connectivity.
Product details
Product details
Physical Parameter
| Size | 172mm*76.6mm*16.5mm |
| Weight | <500g |
| Display Screen | 6.3 inch IPS FHD+ screen((1080*2340) |
| Touching Screen | 5 point G+F+F capacitive screen |
| Battery Capacity | 3.8V /5000mAh detachable |
| Interface | Nano-SIM*2 TF*1(2/3) Type-C support OTG support Power Delivery 2pins Pogo Pin |
| Audio | Loudspeaker Microphone Support voice calls |
| Camera | Front 8 MP Rear 16 MPautofocus camera with flash |
| Notify | Tricolor breathing light motor |
| Key | Power button Volume button+ Volume button- SCAN button Fn |
| Sensor | Gravity sensor/Gyroscope sensor/ Magnetic sensor |
Communication Transmission
| WLAN | Dual-band WIFI (2.4GHz/5Ghz)Support IEEE 802.11 a/b/g/n/ac/ax ready |
| WWAN | CN Version (China/India)2G: GSM: GSM/GPRS/EDGE EGSM900/DCS18003G: WCDMA: B1/B84G: FDD-LTE: B1/B3/B5/B8;TDD-LTE: B34/B38/B39/B40/B41(2535-2655MHz)EAU Version (Europe/The Middle East/Africa/Korea/Thailand/Australia)2G: GSM: GSM850/EGSM900/PCS1900/DCS18003G: WCDMA: B1/B2/B5/B84G:FDD-LTE: B1/B3/B5/B7/B8/B20/B28;TDD-LTE: B38/B40/B41(2496-2690MHz) |
| Bluetooth | BT5.1 |
| GNSS | GPS/Glonass/Galileo |
Standard function
| NFC | Frequency: 13.56MHz Protocol standard: ISO14443A/B,ISO15693, NFC Label standard: M1(S50 S70) CPU NFTags Read-write distance: 2-3cm |
Performance parameter
| CPU | QualcommSM6225 Octa-core 2.4Ghz |
| OS | Android 13.0 |
| RAM+ROM | 4+64GB |
| Extra Memory | Expansible through TF, support 256GB |
Accessories
| Standard Accessories | Power adapter*1 USB data line*1 Battery*1 Protective film*1 Manual*1 Wrist strap*1 |
Optional Function
| 2D Scanning Engine | Scanning Accuracy: ≥3mil |
| Independent Beidou | Support independent Beidou positioning, RTK accurate positioning |
Environmental Parameter
| Operating Temperature | -10°C-50°C |
| Storage Temperature | -40°C-70°C |
| Environment Humidity | 5%RH-95%RH(No condensation) |
| Ingress Protection | IP67 |
| Dropping Height | 1.2M |
